All Way Sign R1-4 – MUTCD Compliant Vector Files

Name: All Way Sign R1-4 – MUTCD Compliant Vector Files
Brand: SignVectors
SKU: PKS-0041
Availability: InStock

Download Free JPG + PNG

This All Way Sign (R1-4) is carefully recreated to match official MUTCD standards, with exact proportions, correct layout, and precise color usage. Details like text spacing, border thickness, and typography follow real-world traffic control specifications to ensure accuracy and readability.

The sign is available in multiple sizes and follows proper MUTCD height, width, and font guidelines, making it suitable for roadside use, planning, mockups, and large-format printing. Official MUTCD color codes and the correct highway sign font are used to maintain a clean, authentic appearance at any scale.

You’ll receive the file in EPS, SVG, PDF, JPG, and PNG formats—each optimized for editing, printing, or digital use. The vector formats allow unlimited resizing without quality loss.

Note: Secure checkout is processed through Gumroad. After completing your purchase, you’ll receive immediate access to download your files. If you need any assistance, please feel free to contact us.

Explore our complete collection of USA MUTCD-compliant signs.

Sign Type	[Regulatory – (R1-4)]
Sign Size	Multiple Mutcd Sizes
Font & Text Height	FHWA Series C
COLORS:	LEGEND — WHITE BACKGROUND — RED

File Details

Compatibility: Illustrator, CAD tools, web & digital use

Select Sign Size (MUTCD):

PDF (Print-ready) $2.99 SVG (Scalable Vector) $3.99 EPS (Editable Master) $4.99

JPG + PNG (Digital Use Only)

Frequently Asked Questions (FAQ)

1. What exactly am I buying?

You’re getting a professionally recreated All Way Sign (R1-4) vector, designed to match official MUTCD standards. Each file has the correct proportions, colors, and fonts, and comes in your choice of size and format.

2. Which file formats do you offer?

We offer JPG & PNG, PDF, SVG, EPS, and a Complete Pack with all sizes and formats. You can pick the exact format you need, and it will be delivered instantly.

3. What sizes are available?

The sign comes in multiple MUTCD-standard sizes:

18 × 6 in (Urban / Local Roads)
24 × 9 in (Conventional Roads)
30 × 12 in (High-Speed Roads)
36 × 15 in (Expressways / Highways)
48 × 18 in (Expressways / Highways)

All sizes follow official proportions, font heights, and color codes.

4. How do I get the exact file I want?

Simply select the size and format on our website, click Buy, and Gumroad will deliver the exact file instantly. No extra downloads, no guesswork.

5. Can I use this for commercial projects?

Yes! Once purchased, you can use these files for design, engineering, planning, or print projects. Just don’t resell the files as-is—they’re meant for your projects only.

6. Can I resize the sign? Will it lose quality?

Absolutely! The vector files (EPS & SVG) are fully scalable, so you can enlarge them for large prints or shrink them for mockups without losing quality.

7. Are these files compliant with MUTCD standards?

Yes, the sign is designed according to official MUTCD guidelines, including correct colors, proportions, and FHWA Highway Gothic font. However, local or state regulations may vary, so always verify before real-world installation.

8. Which software can I use these files with?

The files are compatible with Adobe Illustrator, Photoshop, CorelDRAW, Inkscape, Affinity Designer, and most vector- or raster-based design tools.

9. Can I get all sizes and formats at once?

Yes! The Complete Pack includes all sizes and all formats in a single ZIP. Perfect if you want every version without purchasing them separately.

10. What if I have a problem with my download?

Gumroad handles all downloads automatically. If you run into any issue, contact us directly through Gumroad support or via our website, and we’ll help you get the correct file quickly.

11. Is this file suitable for large-format printing?

Yes! The vector files allow scaling to any size without losing quality, making them perfect for large signs, banners, or mockups. PDFs are also print-ready with accurate real-world dimensions.
